Product Details:
Payment & Shipping Terms:
|
| Type: | Vibrating Screen For Screening Natural Flake Graphite | Application:: | Fine Powder Screening |
|---|---|---|---|
| Voltage:: | 110V/220V/240V/380V | Screening Precision:: | Up To 98% |
| Body Material:: | Carbon Steel/ SS304 / SS316 | Vibrating Motor:: | ABB Or Custom |
| Color:: | According To Different Needs | Tumbler Screen Mesh Area:: | 0.28-5.3㎡ |
| Motor Power:: | 0.75-5.5Kw | Noise Level:: | ≤75dB |
Graphite vibrating sieve sifter is an efficient sieving machine designed for large output, high-density sieving application industries. The simplest sieving method is using your hands with the staring of your eyes. Tumbler sieving machine is the mechanical simulation for this, it is the most effective principle which takes the most effective simulation of the artificial sieving movement (sieving precision, efficiency, service life is 5-10 times than common cylinder sieve), for the processing of all the fine and ultra-fine powder and special materials, particularly suitable for materials which are difficult to classify.
TSM Series Ultrasonic circular Screen Machine(TSM) is one type high capacity, high accuracy and high efficiency screening equipment. It is specially designed to meet clients whoever require high production capacity, high-precision screening.
Rotary Tumbler screen Technical Parameters:
| Model | TSM1000 | TSM1200 | TSM1600 | TSM1800 | TSM2000 | TSM2600 |
| Diameter | 1000mm | 1200mm | 1600mm | 1800mm | 2000mm | 2600mm |
| Area | 0.71 m2 | 1.11 m2 | 1.83 m2 | 2.46 m2 | 3.05 m2 | 5.31 m2 |
| Mesh Size | 0.028mm-12mm | |||||
| Layer(s) | 1-3 | 1-5 | ||||
| Power | 1.5KW | 1.5KW | 3.0KW | 4.0KW | 4.0KW | 5.5KW |
| Net Cleaning | Bouncing ball, Ultrasonic device, Rolling brush | |||||
Tumbler screen equipment Application Industries:
Tumbler can be used for sieving find powder or granules with high capacity and high value, such as, salt, plastic granules, starch, sugar, graphite, rubber powder, chemical powder etc.
1 Up to 5 times outlet compared than common sieving machine.
2 At most 6 Level separation.
3 Sieving efficiency is as high as 90% -95%.
4 When using the silicone rubber balls, ultrasonic and other high-performance mesh- cleaning device system, the sieve aperture will not be blocked.
5 Enclosed cleaning dust, safe operation; The acceleration is 4.5 times lower than common vibrating screen.
6 Noise < 75 dB. Re-optimization is balanced, ground-based dynamic load is low.
